Addonics Technologies – 3-to-5 SA Disk Array User’s Guide v1.0

3

Chapter 1


General Information

The Addonics 3-to-5 Disk Array system makes implementing sophisticated
RAID technology into any computer simple. Designed to accommodate up to
five 3.5" SATA or SATA II hard drives into three 5 ¼” drive bay, each hard
drive can be easily secured inside or removed from the Disk Array rack with
the simple aluminum drive drawer.

Features

Disk Array 5SA - for installing 5 SATA hard drives into three 5 1/4" drive
bay stack

Can be used as an external RAID system using optional external power
adapters(See

power supply requirement

below)

High throughput up to 150 MB/sec with SATA and 300 MB/sec with
SATA II

Full Serial ATA 1.0 and 2.0 compliant

Aluminum frame and drive drawer

Choice of black color bezel or ivory color bezel

Innovative lock and handle for each drive drawer

Drive drawer can be interchanged with the ABS plastic version of the

Drive Cartridge System SA35

.

Use as an external RAID system (require optional external power adapter)

Hot swap

(1)

support

Point to point connection, no cabling needed to install the hard drive into
the drive drawer

SATA 15 pin and standard 4 pin PC power connector

Power switch/LED indicator and over temperature buzzer alarm

Fan switch/LED indicator and failure buzzer alarm

Power switch/LED for each har d drive

Drive can be removed and used as an external Serial hard drive on other
computers with an optional

Serial ATA power adapter.
