Numbers and

Specifications

DVI Output

Selectable output formats:

RGB, video levels (16 - 235)
RGB, PC levels (0 - 255)
YCbCr, 4:2:2, video levels (16 - 235)

(NTSC and PAL discs)

Progressive Component Output

Selectable output formats:

YPbPr, 700 mV, 0% setup
RGB, 700 mV, 0% setup

(NTSC and PAL discs)

Interlaced Component Output

Selectable output formats:

YPbPr, 700 mV, 0% setup

(NTSC and PAL discs)

RGB, 714 mV, 7.5% setup
RGB, 714 mV, 0% setup

(NTSC discs)
