this situation it is usually preferable to use an analog
component connection rather than the DVI
connection. This is because the digital-to-analog
conversion in the Ayre DX-7 will perform at a
higher level than the corresponding conversion in
the display device.
If in doubt about which
connection to use, simply make
a visual comparison to
determine which offers better
performance.
However, a few of these CRT-based displays convert
all incoming signals to digital for certain types of
video signal processing such as scaling. In this case,
using the DVI conversion will be preferred as it
eliminates two extra conversion steps. Consult the
owner’s manual for your display for additional
information.
Component
The component interface is the highest performance
analog interface. The component outputs can be
configured in several ways:
• Interlaced or progressive
• YPbPr or RGB
• Embedded sync or external sync (RGB only)
There are three toggle switches
on the rear panel that
configure the component
signal. Please refer to the
section “Setup and
Configuration”.
When configured as progressive RGB, the sync
(timing) signals can either be added to the Green
connection (Sync on Green, or SoG) for a total of
three wires, or transmitted as separate horizontal
and vertical sync signals (H+V Sync) for a total of
five wires.
