NaceCare Solutions TTV678 - Manual (Page 13)

233890 05/11 (A03)
13
50:1 100:1 75:1 25:1
Adjusting the seat
Setting the cleaning controls
Sitting in the driving position, adjust the seat forwards or backwards as necessary by using the lever
found on the left-hand side (see fig.24).
Note: The seat is fitted with a pressure sensor that disables the machine until an operator is seated.
Fig.24
Insert the key into the ignition and quarter-turn it clockwise to the ‘ON’ position.
The battery charge-level indicator will illuminate.
Set automatic Chemical Dosing Mix as required, depending on floor type and level of soiling.
Set desired Brush Speed as required, depending on floor type and level of soiling.
Set Water Flow Rate as required, depending on floor type and level of soiling
0.25 gpm 0.5 gpm0.75 gpm 1.0 gpm
