RECOMMENDED TOOLS
ROUGHING-IN DIMENSIONS
Customer Service: 561-274-2110
www.decolav.com LET YOUR DREAMS COME ALIVE, YOUR PASSIONS BECOME
REALITY, BE THE ENVY OF YOUR NEIGHBORS ®
Tape Measure
Adjustable Wrench
Drill Level
Phillips
Screwdriver Pipe Wrench
Plumber’s Putty
or Caulking Putty Knife
Flathead
Screwdriver
Scroll Saw Pencil
2 1/2" [6.35cm]
2" [5.08cm]
1 1/4" [3.18cm]
34" [86.36cm]
34" [86.36cm]
5 1/2" [13.97cm]
8" [20.32cm]
1 3/8" [3.49cm]
17" [43.18cm]
17" [43.18cm]
11" [27.94cm]
13" [33.02cm]
12" [30.48cm]
13" [33.02cm]
1 3/4"
[4.45cm]
Finished Wall
Drain
Hole
Faucet Hole Sugg.
Countertop
Waste
Supplies as
required
Suggest
ed
Front View
Finished Floor
Top View
Fitting Line
Side View
Finished Floor
Finished Wall
Suggest
ed
Mounting Clips
Sugg.
MODEL NUMBER: 1210 2
