APPLICATION NOTE AN‐BEI‐E2‐038 Date: 15/02/12
AN‐BEI‐E2‐038 Modbus RTU Control and Register Mapping 5
Register 12: Rating ID
This register gives the following information:
Drive size, drive type, Power units and Power value decimal places
Register value (16 bits HEX format):
X X X X h
Power Units 0 kW
1 HP
Drive Type 4 E2
Power Decimal Places 0 No Decimal Places
1 One Decimal Place
2 Two Decimal Places
Drive Frame Size 1 Frame Size 1
2 Frame Size 2
3 Frame Size 3
NOTE : Power decimal places is used for register 13 (Power rating). For example, if we have value x1x0h in register 12 and value
15 in register 13, this gives the drive power as 1.5KW. If we have value x0x0h in register 12 and same value 15 in register 13, this
gives drive power as 15KW. Or if we have x1x1h in register 12 and 5 in register 13, then the drive power rating is 0.5HP. If we
have x0x1h in register 12 and 5 in register 13, this gives drive power rating as 5HP.
Register 13: Power rating
Combined with the value in register 12, this gives the drive power rating information
Register 14: Voltage level
This register gives the rated input voltage for the drive.
i.e. 230 : 230V
400: 400V 460: 460V
Register 15: Software version
This register contains the drive software version info. Value includes two decimal places.
i.e. 103 means version 1.03
