Hardware
1.1.2 Buzzer In/Out Pin Configuration
There is a buzzer integrated in the front behind the front foil. It can be turned on
or off by a SCOM compatible RBC software command.
It can also be activated by the buzzer-in hardware input according to the following
table.
The resulting buzzer-in signal is evaluated by an OR operation on the signals from
software and hardware.
Buzzer-out is a relay contact parallel to the integrated buzzer that can be used to
switch an external signal device.
The buzzer-in and -out can be connected to the 4-pole Phoenix connector:
1 4
Pin Designation Function
1, 2 Out Buzzer-out, NO-contact, max. load 1 A @ 24 V DC
3 In Buzzer-in, +24 V DC
4 In Buzzer-in, ground
Related information
Buzzer In/Out
1.1.3 Power Remote Pin Configuration
Remote power out is a relay contact that is closed after the power button on the
front side is pressed for more than one second. It is opened after the button is
released. With the remote power out signal, it is possible to switch an external
Beijer Electronics EPC Nautic on and off. The EPC has a corresponding ATX
power remote input. To use this function, connect the double-pole Phoenix
connector to the corresponding connector on the EPC.
1 2
Pin Designation Function
1, 2 Out Remote Power, NO-contact
To be connected to a Beijer Electronics EPC power remote
input.
