Hardware
1 Hardware
An RBC module is a built-in part of an EPC C2D Nautic or an MTe monitor.
Supported features depend on the device.
Component Function Description Device support
4 DIP switches Monitor addressing Monitor Address DIP
Switch Settings EPC C2D Nautic*
MTe monitor
3 buttons Power on/off
Dimming control Dimming EPC C2D Nautic
MTe monitor
Buzzer Buzzer Buzzer In/Out EPC C2D Nautic
MTe monitor
Internal USB
interface USB connection USB Interface EPC C2D Nautic
MTe monitor
COM A
interface RS232/RS485 COM A and COM B Pin
Configuration MTe monitor
COM B
interface RS232/RS485 COM A and COM B Pin
Configuration MTe monitor
Buzzer in/out Buzzer control Buzzer In/Out MTe monitor
Power remote
button Power on/off for
external EPC Nautic Remote Power Out MTe monitor
Internal
4–port USB
2.0 hub USB connection USB Interface MTe monitor
DIP switch Serial mode Serial Mode DIP Switch
Settings MTe monitor
* In order alter the DIP switches to change the default address of the EPC C2D Nautic,
the housing has to be opened.
Related information
DIP Switches
Accessing the DIP Switches
