ADA HANDRAIL INSTALLATION GUIDELINES for
AZEK Premier
AZEK Trademark
AZEK Reserve
Page 2
© 2013 AZEK Building Products. All rights reserved
AZEK Premier AZEK Tr
AZEK Reserve
ademark
ADA COMPLIANT RAILING SYSTEM for
© 2012 All rights reserved. AZEK Building Products, Inc.
www.AZEK.com
Page 2
1.
2.
3.
4.
5.
Hand Rail Bracket
1. Attach bracket to mounting surface
using a 3/8” lag bolt provided with Hand Rail Bracket.
2. Place rail at appropriate location on bracket.
3. Pre-drill two holes in rail with a 1/4” bit at appropriate
location and attach with screws provided.
4.
5.
Snap bolt cover into place.
(sold separately) to end of rail.
1.
Cut the aluminum and
PVC tube to proper length.
1. Apply adhesive to all metal contact surfaces.
2
3. Insert straight wall return into aluminum rail support.
4.
cover into place. Screws provided are for attachment to AZEK
post sleeve and are not meant for other surfaces.
Ensure adhesive cures per adhesive
manufacturers instructions.
Straight Wall Return
Ensure adhesive cures per adhesive
manufacturers instructions.
90° Wall Return
1.
2.
3.
4.
Cut the aluminum and
PVC tube to proper length.
1. Apply adhesive to all metal contact surfaces.
2
3. Slide joiner into wall return and aluminum rail support.
4.
into place. Screws provided are for attachment to AZEK
post sleeve and are not meant for other surfaces.
Cut the aluminum and PVC tube
to proper length.
1. Apply adhesive to all metal
contact surfaces.
2. Slide joiner into each side
of corner and aluminum rail
supports until the joints are tight.
Ensure adhesive cures per adhesive
manufacturers instructions.
1.
2.
2.
90° Corner
2.
4.
3.
Using PVC adhesive, attach hand rail end cap
