GENERAL SPECIFICATIONS
WallVIEW PRO EagleEye System
System Part
Numbers 999-9500-000 North America
999-9500-001 International
Quick-Connect PRO Universal Interface
Connectors Power Connector: 5.5mm OD x 2.5mm ID
Power RJ-45: Supplies 36V to EZCamera Interface Module Regulator
IR: 2-Pin Phoenix type spring cage connector
Video Outputs: BNC Connectors for HD Analog Component (Y,PB,PR)
Video RJ-45: Transports HD or SD video from camera
Camera Select
Switch 8-Position DIP switch loads camera profiles and IR Forwarding for Polycom HDX-9000 Codecs
Video Adjustments Y-Gain (luminance gain) for fine tuning over longer cable distances
Distance Compensation: 100’, 200’, 300’, 400’+
IR Gain
Adjustment IR Gain for fine tuning IR over 300 feet
Compatible
Cameras Sony BRC-H700, BRC-Z700, EVI-HD1, BRC-300, (EVI-D70, EVI-D100 also in SD Mode)
Polycom EagleEye
Max. Cat. 5 Cable
Distance Up to 500’ (152.4m) for Video Power and Control
Power Supply 36 VDC, 2.78 Amp
Dimensions 1-RU Rack Mount (1.75” H x 19” W x 6” D)
EZCamera Interface Module
Connectors Four (4) RJ-45 Connectors
One DB-25 for Power, Video, Control & IR
Cable Assembly For Polycom EagleEye: DB-25M to HDCI -M
Power Regulator Supplies 12VDC to Cameras
Dimensions Approx. (3.035” H x 4.46” W x 1.242” D)
