WallVIEW Universal CCU HD-22/30
Vaddio WallVIEW Universal CCU Cat-5 Version. Document Number 342-0645 Rev C Page 8 of 20
The HD-22 and HD-30 Control Menu Screens
The HD-22 and HD-30 have individual firmware that auto loads when the camera is plugged in to the Universal
CCU and the CCU is turned on (turn the camera on first). Since most cameras are a bit different, the menus will
be slightly different, but the Firmware is the same for the HD-22 and HD-30. The menus are organized as follows:
Image: Menu Organization HD-22/30
The HD-22 and HD-30 individual control screens are very similar, only differing in lens magnification and product
name. Both cameras will perform well for low light, conferencing and large room applications.
The Main Menu screen shows eight (8) prominent parameters at a time. For both cameras, the BRIGHT key will
actually read out on the display as PEDESTAL. This control is actually PEDESTAL and the display is correct.
The button will be eventually changed to read PED (since pedestal won’t fit).
The Cat-5 Adjustment Menu allows the user to adjust the skew of the Cat-5 Cable (1 to 16), to compensate for
differing Cat-5 cable lengths between camera and CCU. This setting will usually be best in the middle of the
range of skew numbers which pass acceptable video. Set the HDMI Color Space to YCbCr for HDMI and to
sRGB for DVI-D output. The Y-Gain is for adjusting the video ±10 IRE at all outputs as needed for associated
equipment. Preset Lighting Scene Configurations offer sample settings for fluorescent, incandescent and
outdoor lighting environments. Choose the scene (shown in the Screen Config description below) which looks
best for your situation and fine tune from there.
The Cat-5 Adjustment menu uses the “@’ sign for the cursor and the “>” when selected.
Scene Configuration:
Generalized Scene Configurations have been added to allow the user to quickly run through preset lighting
environment scenes, and include the following presets:
1) AUTO (full Auto)
2) Incand Lo (incandescent low)
3) Incand Hi (incandescent high)
4) Fluor Lo (fluorescent low)
5) Fluor Hi (fluorescent high)
6) Outdoor
Main Menu Pages HD-22
Main Control Menu
8-Most used Controls
displayed
CAT-5 Adjust Menu
With Skew, Color Space
Y-Gain and Six preset
Scene Configurations
LED Display Menu
For set up of front
panel LED display Camera Info Menu
Versions of camera
hardware
For this Menu, put
Dip Switch 5 UP
For this Menu, put
Dip Switch 5 UP
Cat-5 Adjustment Menu HD-22/30 with Scene >4: Fluorescent High
CAT-5 CCU HD-22
@
Skew 1 Scene Config
HDMI YCbCr >1: AUTO
YGain Def
CAT-5 CCU HD-30
Skew 1 Scene Config
@
HDMI YCbCr >4: Fluor Hi
YGain Def
Cat-5 Adjustment Menu HD-22/30 with Scene >1: AUTO
CAT-5 CCU HD-22
RED 65 GAMMA 1
BLUE 75 DETAIL 44
CHROMA 190 IRIS AUTO
PEDESTAL 111 GAIN AUTO
CAT-5 CCU HD-30
RED AUTO GAMMA 1
BLUE AUTO DETAIL 44
CHROMA 190 IRIS AUTO
PEDESTAL 111 GAIN AUTO
Main Menu Pages HD-30
