BRC-Z700 Command List (2/5)
* See the section under VISCA Command Setting Values.
Command Set Command Command Packet Comments
CAM_RGain Reset 8x 01 04 03 00 FF
Up 8x 01 04 03 02 FF
Down 8x 01 04 03 03 FF
Direct 8x 01 04 43 00 00 0p 0q FF pq: R Gain (00 - FF)
CAM_BGain Reset 8x 01 04 04 00 FF
Up 8x 01 04 04 02 FF
Down 8x 01 04 04 03 FF
Direct 8x 01 04 44 00 00 0p 0q FF pq: B Gain (00 - FF)
CAM_COLOR_GAIN Up 8x 01 04 09 02 FF
Down 8x 01 04 09 03 FF
Reset 8x 01 04 09 00 FF
Direct 8x 01 04 49 00 00 00 0p FF p: 0 - E
CAM_WB_Sens Low 8x 01 04 56 01 FF
Middle 8x 01 04 56 02 FF
High 8x 01 04 56 03 FF
CAN_ColorMatrix On 8x 01 7E 01 3D 02 FF
Off 8x 01 7E 01 3D 03 FF
R.ENHANCE 8x 01 7E 01 47 0p 0q FF pq: 00 - 14
G.ENHANCE 8x 01 7E 01 48 0p 0q FF pq: 00 - 14
B.ENHANCE 8x 01 7E 01 49 0p 0q FF pq: 00 - 14
YL.ENHANCE 8x 01 7E 01 50 0p 0q FF pq: 00 - 14
CY.ENHANCE 8x 01 7E 01 51 0p 0q FF pq: 00 - 14
MG.ENHANCE 8x 01 7E 01 52 0p 0q FF pq: 00 - 14
CAM_AE Full Auto 8x 01 04 39 00 FF
Manual 8x 01 04 39 03 FF
Shutter Priority 8x 01 04 39 0A FF
Iris Priority 8x 01 04 39 0B FF
Gain Priority 8x 01 04 39 0E FF
CAM_AE_Speed Low 8x 01 04 5D 01 FF
Middle 8x 01 04 5D 02 FF
High 8x 01 04 5D 03 FF
CAM_AGC_LIMIT Direct 8x 01 04 2C 0p FF p: Gain Limit*
CAM_IRIS_LIMIT Direct 8x 01 04 2B 0p FF p: Iris Limit*
CAM_Shutter Reset 8x 01 04 0A 00 FF
Up 8x 01 04 0A 02 FF Shutter setting (1/60sec - 1/10000sec [59.94i])
(1/50sec - 1/10000sec [50i])
Down 8x 01 04 0A 03 FF
Direct 8x 01 04 4A 00 00 0p 0q FF pq: Shutter Speed Setting*
CAM_Iris Reset 8x 01 04 0B 00 FF
Up 8x 01 04 0B 02 FF
Down 8x 01 04 0B 03 FF
Direct 8x 01 04 4B 00 00 0p 0q FF pq: Iris Value Setting*
CAM_Gain Reset 8x 01 04 0C 00 FF
Up 8x 01 04 0C 02 FF
Down 8x 01 04 0C 03 FF
Direct 8x 01 04 4C 00 00 0p 0q FF pq: Gain Level Setting*
CAM_ExpComp On 8x 01 04 3E 02 FF
Off 8x 01 04 3E 03 FF
Reset 8x 01 04 0E 00 FF
Up 8x 01 04 0E 02 FF
Down 8x 01 04 0E 03 FF
Direct 8x 01 04 4E 00 00 00 0p FF p: ExpComp Level Setting*
