Quick-Connect 4
Vaddio Quick-Connect 4 - Document 341-256-1 Rev C
Page 4 of 8
4-Camera
Direct Control
Example
(4-Control Ports)
ProductionVIEW
&
Quick-Connect 4
4-Camera
Quick-Connect 4
Head End Daisy
Chain Example
(1-Control Port)
Note: Cat. 5 Cable
Maximum Length for
this Control
Configuration:
50’/15.24m
Power & Video
RS-232
RS-232
RS-232
Cat. 5
RS-232
Cam 3
S-Video
Cam 1
S-Video
Cam 2
S-Video Cam 4
S-Video
RS-232
Power & Video
Power & Video
Power &
Video
Control
Source
3-Cat.5
Homeruns
2-Cat.5
Homeruns
3-Cat.5
Homeruns
Figure 5:
Vaddio
ProductionVIEW FX
(6 discrete control ports -
no daisy chain control)
Figure 6: Head End Daisy Chain Example (see Figure 7 for I/O detail)
Cat. 5
Cat. 5
Cat. 5
Cat. 5
Cat. 5
Cat. 5
