Quick-Connect 4

Vaddio Quick-Connect 4 - Document 341-256-1 Rev C

Page 3 of 8

BASIC CAMERA

CONNECTION

































4-Camera
Daisy Chain
Control Example
(1-Control Port)

ControlVIEW
Xtreme &
Quick-Connect 4







































RS-232 from

Controller

DB-9 or RJ-45

S-Video

Output

Composite

Video

Output

Power Supply

Vaddio Model 100 PTZ
with Camera Shoe

Power to Camera,
S-Video and
Composite Video
from Camera
over Single Cat. 5

RS-232
on Cat. 5

Figure 4:

Daisy Chain Example with Single Control Port

RS-232
DB-9 to DB-9

Camera 1

S-Video

Output

Camera 3

S-Video

Output

Camera 2

S-Video

Output

Camera 4

S-Video

Output

RS-232

RS-232

RS-232

RS-232

Power

Power & Video

Power & Video

Power & Video

Power & Video

Cam 1

Cam 2

Cam 3

Cam 4

Figure 3: Single Camera Connection

Vaddio ControlVIEW Xtreme

IN

IN

IN

IN

OUT

OUT

OUT

Cat. 5

Cat. 5

Cat. 5

Cat. 5

Cat. 5

Cat. 5

Cat. 5

Cat. 5
