System connectivity example – Vaddio Image Controller CeilingVIEW HD-18 DocCAM User Manual
Page 6

CCU Image Controller for CeilingVIEW HD-18 DocCAM
CCU Image Controller for CeilingVIEW HD-18 DocCAM - Document 342-0197 Rev. A
Page 6 of 12
System Connectivity Example
:
Featuring the CeilingVIEW HD-18 DocCAM, Quick-Connect DVI/HDMI SR
Interface, CeilingVIEW HD-18 Series CCU Image Controller & ProductionVIEW HD
Two (2) Cat-5e Cables
Up to 100’ (30.48m)
Cat-5e Cable:
Power to Camera - HSDS Video from CeilingVIEW HD-18
CeilingVIEW
HD-18
DocCAM
RS-232
YPbPr
Up to 1080p/60
*Simulated Video Feeds
RS-232
RS-232
HD
Monitors*
Vaddio ProductionVIEW HD
CCU Image Controller for CeilingVIEW
PREVIEW
PROGRAM
Quick-Connect DVI/HDMI
SR Interface
HD YPbPr or
SD or RGBHV
RAR
