TurboChef Technologies i3 EN - Manual (Page 22)

THE INFO MODE 14
Overview of the Info Mode
The info mode serves four main purposes:
1. To display general oven information.
2. To provide access to test mode and additional
diagnostic tools for service technicians.
3. To turn oven options and features on/off.
4. To update oven settings.
To access the info mode, simply press the Info key
when the oven is either off or cooling down. To toggle
between the Info screen 1 and 2, press the up or
Down key.
Screen 1 of the info mode (Figure 20) includes:
- oven serial number
- oven software version
- Menu part number and revision
- Last temperature selected to cook
- Current electrical compartment temperature
- Counters (scroll by pressing adjacent soft key)
- operating voltage (uSA models only)
- Access to the fault log
- Access to service phone numbers
Screen 2 of the info mode (Figure 21) includes:
- Access to test mode
- Access to the “options” screen
- Language (set by pressing adjacent soft key - not
available on all models)
- Access to date/time settings
- Sound (press adjacent soft key to increase/decrease
the volume)
- Access to the “Load Menu” screen
- F2 alarm on or off (see page 15 for details)
viewing Cook Counter/Time Logs
From the info mode (Figure 20), press the r1 soft key:
- once to display the cook counter.
- Twice to display total cook time.
- Three times to display total magnetron time.
- Four times to display total “oven on” time.
viewing the Fault Log
From the info mode (Figure 20), press the r3 soft
key to view the fault log (Figure 22). To view a
detailed log of each fault occurrence (Figure 23), press
the soft key adjacent to the fault code.
BACK
STOP
ENTER
1 2
A B C
3
D E F
4
G H I
5
J K L
6
M N O
BACK
STOP
ENTER
7
P Q R S
8
T U V
9
W X Y Z
0
MENU P/N AND REV
INFO 1
13
SOFTWARE VERSION
SP: 500F
EC TEMP: 84F
SERIAL NUMBER
FAULT LOGS
VAC = 240
SERVICE NUMBERS
COUNTS SCROLL
BACK
STOP
ENTER
1 2
A B C
3
D E F
4
G H I
5
J K L
6
M N O
BACK
STOP
ENTER
7
P Q R S
8
T U V
9
W X Y Z
0
SET LANGUAGE
INFO 2
14
SET OPTIONS
SET DATE/TIME 05/01/09 11:14:28
TEST MODE LOAD MENU
SOUND = = = = = = 7
F2 ALARM ON
Figure 20: Info Mode Screen 1
Figure 21: Info Mode Screen 2
BACK
STOP
ENTER
1 2
A B C
3
D E F
4
G H I
5
J K L
6
M N O
BACK
STOP
ENTER
7
P Q R S
8
T U V
9
W X Y Z
0
F6: EC OT
F8: HX RISE LOW
F1: BLOWER
F2: LOW TEMP
F3: MAG C LOW
F4: MONITOR
F5: MAG OT
FAULT LOG
8
0
0
0
0
F7: RTD OPEN
0
0
0
Figure 22: Fault Log
BACK
STOP
ENTER
1 2
A B C
3
D E F
4
G H I
5
J K L
6
M N O
BACK
STOP
ENTER
7
P Q R S
8
T U V
9
W X Y Z
0
07/14/07 05:22
F1 FAULT DETAIL
Press to return to “Shutting Down”
Press to return to main Fault Log screen
40
07/14/07 13:54
07/14/07 22:07
07/15/07 08:36
07/18/07 14:35
09/26/07 17:42
12/04/07 20:18
MORE
Press to advance to earlier fault occurrences
Press to return to more recent fault occurrences
Figure 23: Fault Detail
