28
Component Operation and Checks
Programming the Heat Controller
Make sure the DIP switch is set correctly. To check the DIP switch, remove the control
chassis from the case. Holding each side of the bezel, press in firmly on the side grips until
the tabs release. You may have to rock the bezel back and forth several times to release the
chassis. Pin 1 should be “OFF”, pin 2 should be “ON”
To program, use the "up' and "down" arrows to change settings. The mode button is to the
left of the "up" arrow and is not labeled.
1 Push "up" and "down" arrows simultaneously for 5 seconds.
Display to read "0" on top
"LOC" on bottom
---------------------------------------------------------
2 Push mode "J" on top
"In" on bottom
--------------------------------------------------------
3 Push mode "F" on top
"C-F" on bottom
---------------------------------------------------------
4 Push mode "114" on top
"rL" on bottom
----------------------------------------------------------
5 Push mode "120" on top
"rH" on bottom
----------------------------------------------------------
6 Push mode "HT" on top
"Ot 1” on bottom
----------------------------------------------------------
7 Push mode "3" on top
"HSC" on bottom
----------------------------------------------------------
8 Push mode "no" on top
"Ot 2" on bottom
----------------------------------------------------------
9 Push modes "OFF" on top
"rP" on bottom
------------------------------------------------------------
