Nor-Lake AdvantEDGE Chef Base User Manual
Page 5
08/13 Rev. E 147774
5
ITEM
NUMBER
PART NAME
DESCRIPTION
CB53
CB60
CB72
CB84
CB96
P/N
1
Cabinet Rail Assy - Left
X
X
X
X
X
149811
2
Cabinet Rail Assy - Right
X
X
X
X
X
149812
3
Crossbar Rail Assy - Left
X
X
X
149813
4
Crossbar Rail Assy - Right
X
X
X
149814
5
Tray Frame - Big
STS445NF
X
X
X
X
149815
6
Tray Frame - Small
STS445NF
X
X
149816
7
Door Assy - Big
STS430, URT, 53,60, 83(86)(84), 96
X
X
X
X
149817
8
Door Assy - Small
STS430, URT, 71(74)(72), 83(86)(84)
X
X
149818
9
Door Gasket
PVC-S 71(74)(72), 83(86)(84)
X
X
149819
10
Door Gasket
PVC-S 53,60, 83(86)(84), 96
X
X
X
X
149820
11
Condenser
10S*4R, 3/16" ST
X
X
X
149821
12
Condenser
10S*6R, 3/16" ST
X
X
149822
13
Condenser - Hot Pipe
OD 1/3" CU Pipe
X
X
X
X
X
145712
14
Evaporator Assembly
4S*3R, 3/8" CU, 342mm
X
X
X
149823
15
Evaporator Assembly
4S*3R, 3/8" CU, 700mm
X
X
149824
16
Drier
XH-9, 18g
X
X
X
X
X
145714
17
Capillary & Suc Pipe Assy cu pip7.94, ID1.2 x L1650
X
X
X
X
X
149825
18
Thermostat Control
GNA-240L
X
X
X
X
X
145727
19
Knob
ABS
X
X
X
X
X
145730
20
Thermostat Plate
Stainless Steel
X
X
X
X
X
145821
21
Compressor
SD162C-L1U, 53,60, 71,72
X
X
X
145735
22
Compressor
SK1A1C-L2W, 83,84, 96
X
X
145736
23
Harness Main
AWM1015
X
X
X
X
X
149826
24
Harness Comp.
AWM1015(SK162C-L1U)
X
X
X
149827
25
Harness Comp.
AWM1015(SK1A1C-L2W)
X
X
149828
26
Main Power Cord
125V 15A
X
X
X
X
X
145733
27
Indicator
TID-1110 - 115V, °F
X
X
X
X
X
149829
28
Condenser Fan Motor
115V/6W/CW
X
X
X
X
X
145751
29
Condenser Fan Motor Blade
AL, Φ110
X
X
X
X
X
145750
30
Evaporator Fan Motor
115V/60Hz, DAI6122 FRTA
X
X
X
X
X
145709
31
Evaporator Fan Blade
ABS, Φ110
X
X
X
X
X
145710
32
Supporter Pan (A)
STS445NF, T1.0
X
X
X
X
X
149830
33
Supporter Pan (B)
STS445NF, T1.0
O
O
O
O
O
149831
34
Side Cover
STS430
X
X
X
X
X
149832
35
Front Cover
STS430
X
X
X
X
X
149833
36
Back Cover
GI
X
X
X
X
X
149834
37
Evap. Fan Guard - Small
STS445NF
X
X
149835
38
Evap. Fan Guard - Large
STS445NF
X
X
X
149836
39
Evap. Duct (2 fan)
STS445NF
X
X
149837
40
Evap. Duct (3 fan)
STS445NF
X
X
X
149838
41
Caster Set
4" 1 Brake Caster & 1 Regular Caster
X
X
X
X
X
149839
