APPENDIX
TAB.1a
Model
BCF44244–BCB44244
BCF93558
BCF11514
BCF22020
Gross weight [lb]
276
485
551
706
Net weight [lb]
254
430
485
640
Dimensions
29-5/16”x27-9/16”
x33-1/2”/39-3/8”
31-1/2”x32-11/16”
x68-15/16”
40-15/16”x39-5/8”
x73-5/8”
40-15/16”x39-5/8”
x73-5/8”
Capacity
Mass /cycle [lb]
22
44
55
88
Internal volume [cu.ft.]
2.55
5.52
13.58
13.58
Grids
4
3
6
10
Power supply
Voltage [V]
220 ~
220 ~
220 ~
220 ~
Frequency [Hz]
60
60
60
60
Intensity [A]
5.5
12.5
13.3
17
Phase
1 ph
3 ph
3 ph
3 ph
Refrigerating unit
Refrigerating power [W]
617
2011
2011
2400
Evaporation temperature [°F]
-22
-22
-22
-22
Cooling temperature [°F]
+194 to +38
+194 to +38
+194 to +38
+194 to +38
Cooling time [min]
150
150
150
150
Freezing temperature [°F]
+194 to 0
+194 to 0
+194 to 0
+194 to 0
Freezing time [min]
240
240
240
240
Condensation temperature [°F]
+130
+130
+130
+130
Max room temperature [°F]
+90
+90
+90
+90
Compressor type
Hermetic
Hermetic
Hermetic
Hermetic
Fluid refrigerant
R404a
R404a
R404a
R404a
Fluid refrigerant qty [lb]
3
4.4
5
7.7
Condenser type
Air
Air
Air
Air
Noise [dB] (A)
65
72
72
72
IFR
Multi-detector probe
Cooling time increases by 20% if the machine is installed too close to a wall.
TAB.1b
Model
BC40-4
BC80-8
BC113-14
Gross weight [lb]
276
485
551
Net weight [lb]
254
430
485
Dimensions
29-5/16”x27-9/16”
x33-1/2”/39-3/8”
31-1/2”x32-11/16”
x68-15/16”
40-15/16”x39-5/8”
x73-5/8”
Capacity
Mass /cycle [lb]
22
44
55
Internal volume [cu.ft.]
2.55
5.52
13.58
Grids
3
3
6
Power supply
Voltage [V]
220 ~
220 ~
220 ~
Frequency [Hz]
60
60
60
Intensity [A]
3.5
5
6
Phase
1 ph
3 ph
3 ph
Refrigerating unit
Refrigerating power [W]
692
2245
3325
Evaporation temperature [°F]
14
14
14
Cooling temperature [°F]
+194 to +38
+194 to +38
+194 to+38
Cooling time [min]
180
180
180
Freezing temperature [°F]
-
-
-
Freezing time [min]
-
-
-
Condensation temperature [°F]
+130
+130
+130
Max room temperature [°F]
+90
+90
+90
Compressor type
Hermetic
Hermetic
Hermetic
Fluid refrigerant
R404a
R404a
R404a
Fluid refrigerant qty [lb]
2.2
4
4.4
Condenser type
Air
Air
Air
Noise [dB] (A)
65
72
72
IFR
Multi-detector probe
Cooling time increases by 20% if the machine is installed too close to a wall.
