BP SYSTEM & TP800/TP900/SPATOUCH™ SOFTWARE VERSION REqUIREMENTS
BP system at version 20.0 or later and one of the following:
TP800 at version 1.13 or later
TP900 at version 1.13 or later
spaTouch at version 1.4 or later
The system and panel version numbers can be found using any of these panels by going to
Settings -> Information.
bba™ Specifications:
Speaker Impedance ……………………….… 2 – 8 ohms
Output Power (2 ohm load) ………………… 30 W RMS per channel
(4 ohm load) ………………… 20 W RMS per channel
Frequency Response ……………………….. 20 Hz – 40,000 Hz
Low Pass Crossover ……………………..…. 18 Hz – 245 Hz
Operating Voltage ………………….. ……… 13.8V (10V – 16V) DC
Maximum current draw (full power) ……….. 8 – 10 amps
Dimensions (approx. w/h/d)
Amplifier ………………..…………… 224mm X 106mm X 39mm
8.82 X 4.17 X 1.54 inches
Weight …………………………………..…….. 1.91 lbs
Installation Clearance (recommended)…….. 10 inches free space top
Intellectual Property Advisement
All Intellectual property, as defined below, owned by or which is otherwise the property of Bal-
boa Water Group or its respective suppliers relating to the Balboa Water Group including but
not limited to, accessories, parts, or software relating thereto bba™ - Balboa Bluetooth Audio
(AMP) (the “System”), is proprietary to Balboa Water Group and protected under federal laws,
state laws, and international treaty provisions. Intellectual Property includes, but is not limited
to, inventions (patentable or un-patentable), patents, trade secrets, copyrights, software, com-
puter programs, and related documentation, and other works of authorship. You may not in-
fringe or otherwise violate the rights secured by the Intellectual Property. Moreover, you agree
that you will not (and will not attempt to) modify, prepare derivative works of, reverse engineer,
decompile, disassemble, or otherwise attempt to create source code from the software. No title
to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intel-
lectual Property shall remain with Balboa Water Group and its suppliers.
