A-ix
ATTO Technology Inc. Diamond Storage Array Installation and Operation Manual
Appendix D Sample Zoning Command Sequences
First time configuration (after download)
QuickRAID under Zoning “first time” configuration,
an all/all/all configuration in the selected QuickRAID
configuration. All zone commands except ZoneCommit affect only the planned configuration.
ZoneCommit sets the Planned Configuration into the
Active Configuration.
Simple configuration
2 hosts. Hosts can use different operating systems. All
zone commands except ZoneCommit affect only the planned configuration. ZoneCommit sets the Planned
Configuration into the Active Configuration.
Symmetric Model
1 host, 1 switch. All host ports travel through a switch
to both Diamond ports. Zoning is not required, since
there is no reason to restrict host/HBA/Port access. All zone commands except ZoneCommit affect only the
planned configuration. ZoneCommit sets the Planned
Configuration into the Active Configuration.
ZoneClearAll Clears any previously-defined zones
ZoneCommit Sets the new zoning configuration.
ZoneClearAll Clears any previously defined zones from the planned
configuration.
ZoneCreate zone_1 Creates a zone named zone_1
ZoneAddHost zone_1 20:00:00:10:86:00:01:34 Adds host WWPN to zone_1
ZoneAddDevice zone_1 1 4 Adds LUN 1 and 4 to zone_1
ZoneAddPort zone_1 0 LUN 1 and LUN 4 will be available through HIC 0 for only the host
in zone_1
ZoneCreate zone_2 Creates a zone named zone_2
ZoneAddHost zone_2 20:00:00:60:00:00:12:34 Adds host WWPN to zone_2
ZoneAddDevice zone_2 7 Adds LUN 7 to zone_2
ZoneAddPort zone_2 1 LUN 7 will be available through HIC 1 for only the host in zone_2
ZoneState zone_1 enabled Enables zone_1.
ZoneState zone_2 enabled Enables zone_2.
ZoneCommit Sets the Planned Zoning Configuration into the Active
configuration. No other LUNs will be available to any host.
ZoneClear all Clears any previously-defined zones from the planned configuration
ZoneCommit Copies what is in the Planned Zoning Configuration to the Active Configuration: in this case, clears
any previously-defined zones.
