American-Lincoln Technology 3-9
114 RS Operator’s Manual
KEY NO. PART NUMBER DESCRIPTION QTY
1 2-00-04282 Terminal 1
2 3-61-00189 Wire, #16 AWG. (Black) 12'
3 2-00-04578 Terminal, Male Bullet 4
4 2-00-04626 Terminal, Female Bullet 4
5 3-61-00193 Wire, #16 AWG. (Red) 12"
6 8-40-05036 Strobe Light, Amber (OPTION 0880-588) 1
8-58-05020 Strobe Light, Red (OPTION 0880-589) -
7 8-58-05228 Panel Light Support 1
8 8-20-06036 Duct, Wire Strip 1
9 2-00-01915 Grommet 1
10 2-00-05261 Threaded Insert 4
11 2-00-03418 Connector 1
12 2-00-01246 Nut, Hex Fiber Insert #10-24 2
13 2-00-03063 Screw, #10-24 x .750 THM 2
14 2-00-00205 Screw, 1/4-20 x 1.000 HHC 4
15 2-00-00518 Lock Washer, Helical Spring 4
C-0561
STROBE LIGHT W/OVERHEAD GUARD
C-0561/9802
13
14
15
6
7
10
8
9
4
11
1
5 2
3
