3-2 American-Lincoln Technology
114 RS Operator’s Manual
OPTION 0880-580
KEY NO. PART NUMBER DESCRIPTION QTY
1 8-75-01120 Spacer 2
2 7-82-00023 Switch 1
3 8-32-09009 Back-Up Alarm 1
4 8-64-00007 Circuit Breaker, 10 amp 1
5 8-11-00044 Boot 1
6 2-00-03418 Terminal 1
7 2-00-04479 Connector, 3-Way 1
8 3-61-00193 Wire, 16 ga. Red 6'
9 2-00-04626 Terminal, Female Bullet 2
10 2-00-04578 Terminal, Male Bullet 2
11 3-61-00189 Wire, 16 ga. Black 8'
12 2-00-04282 Terminal Ring 1
13 2-00-04345 Tye Raps 10
14 2-00-04742 Terminal Ring 2
15 2-00-00221 Screw, 1/4-20 x .750 HHC 2
16 2-00-00594 Nut, Hex 1/4-20 x .437 x .218 2
17 2-00-01490 Screw, 1/4-20 x .875 HHC 2
18 2-00-03702 Washer, .625 x .281 x .063 2
19 2-00-00624 Nut, #6-32 Hex 2
20 2-00-00455 Flat Washer, .375 x .156 x .047 2
21 2-00-05063 Screw, #6-32 x 2.000 Lg. RHM 2
22 2-00-00518 Lock Washer, Helical Spring 2
C0485
BACK-UP ALARM - PARTS LIST
