User Guide P. 17
Intrusion Codes through the LED Light
If there has been an intrusion in the vehicle while it was locked and armed, the LED will provide an
intrusion code matching the type of the intrusion that took place. Disarm the alarm (
UNLOCK ) to identify
the intrusion. The LED intrusion codes are flashed in continuous loops:
2 x = Doors intrusion
3 x = Shock Sense
4 x = Hood 5 x = Panic
6 x = Ignition
7 x = Trunk
The alarm diagnostic by LED projects an LED flash sequence immediately after disarming and will
remain in that state of alarm memory until the ignition is turned ON.
Diagnostics – Chirps Table
Chirps Description
1
• Doors locked, alarm and starter kill armed.
• LOCK confirmation.
• Entering mode 1 in the programming options.
2
• Doors unlocked, alarm and starter kill disarmed.
• Transmitter programmed.
• Entering mode 2 in the programming options.
3
• LOCK and arm while a zone is left unprotected.
• Entering mode 3 in the programming options.
4
• UNLOCK and disarm: an intrusion was detected (in warning chirps mode or full chirps
mode).
• Entering tach programming mode.
• Entering mode 4 in the programming options.
5 • Siren or horn chirp timing adjustment
Constant
up to 60 sec
• In siren or horn mode: alarm condition generated by an intrusion, by panic mode or
when the system is powered up. The siren will sound for 60 sec.
