5.5.3 Rebuilding a RAID set
To rebuild a RAID set:
1. From the Array List, use the up or down arrow keys to select the RAID set you
want to rebuild, then press . The RAID set details appear.
MediaShield BIOS Apr 20 2007
- Array List -
Boot Status Vendor Array Size
YES Healthy NVIDIA STRIPE XXX.XXG
NO Healthy NVIDIA MIRROR XXX.XXG
[Ctrl-X]Exit [↑↓]Select [B]Set Bootable [N]New Array [ENTER] Detail
2. Press . The RAID details appear.
[R] Rebuild [D] Delete [C] Clear MBR [ENTER] Return
Array 3 : NVIDIA MIRROR XX.XXGB
- Array Detail -
RAID Mode: Mirrored
Stripe Width: 1 Stripe Block: 64K
Port Index Disk Model Capacity
0.0 1 XXXXXXXXXXXXXXXXX XXX.XXGB
1.1 0 XXXXXXXXXXXXXXXXX XXX.XXGB
