Asus M2N-L - Manual (Page 11)

xi
M2N-L specifications summary
*Specifications are subject to change without notice.
Networking LAN Dual Onboard Marvell ® 8056 PCIe GbE LAN
controllers
Graphic VGA XGI ® Volari™ Z9s VGA Controller / 32MB
DDR2 DRAM
Onboard I/O
Connectors
Floppy Connector 1
PSU Connectors 24-pin ATX power connector + 4-pin ATX 12V
power connector
USB Connectors 1 (for 2 USB 2.0/1.1 ports)
Fan Headers 4 x 3-pin (CPU_FAN1, FRNT_FAN1/2,
REAR_FAN1)
Chassis Intruder 1
Serial Port Header 1
Rear I/O
Connectors
External Serial Port 1
External USB ports 2 (Both support USB 2.0/1.1)
VGA Port 1
RJ-45 Port 2
PS/2 KB/Mouse 1 mouse port + 1 keyboard port
Management
Solutions
Software ASWM 2.0
Monitoring CPU Temperature �
FAN RPM �
EMI US (FCC, CFR47
Part 15, Class B)
�
Europe (CE,
EN55022 & EN
55024)
�
Environment Operating temperature: 10 o C ~ 35 o C
Non operating temperature: -40 o C ~ 70 o C
Non operating humidity: 20% ~ 90%
(Non condensing)
