ECC Configuration
The ECC configuration menu allows you to change the ECC settings.
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
ECC Configuration
ECC Mode [Disabled]
DRAM ECC Enable [Disabled]
DRAM SCRUB REDIRECT [Disabled]
4-Bit ECC Mode [Disabled]
DRAM BG Scrub [Disabled]
Data Cache BG Scrub [Disabled]
L2 Cache BG Scrub [Disabled]
L3 Cache BG Scrub [Disabled]
DRAM ECC allows
hardware to report
and correct memory
errors automatically
maintaining system
integrity.
ECC Mode [Disabled]
Allows you to set the ECC configuration. Configuration options: [Disabled]
[Basic] [Good] [Super] [Max] [User]
The flowing items are changeable when the ECC Mode is set to [User].
DRAM ECC Enable [Disabled]
Enables or disables the DRAM ECC that allows the hardware to report and
correct memory errors automatically. Configuration options: [Disabled]
[Enabled]
DRAM SCRUB REDIRECT [Disabled]
Enables or disables the DRAM SCRUB REDIRECT feature that allows the
system to correct the DRAM ECC errors immediately when they occur.
Configuration options: [Disabled] [Enabled]
4-Bit ECC Mode (or ECC Chip Kill) [Disabled]
Enables or disables the ECC chip kill feature.
Configuration options: [Disabled] [Enabled]
DRAM BG SCRUB [Disabled]
Sets the DRAM BG Scrub. Configuration options: [Disabled] [40ns] [80ns]
[160na] [320ns] [640ns] [1.28us] [2.56us] [5.12us] [10.2us] [20.5us]
[41.0us] [81.9us] [163.8us] [327.7us] [655.4us] [1.31ms] [2.62ms] [5.24ms]
[10.49ms] [20.97ms] [42.00ms] [84.00ms]
Data Cache BG Scrub [Disabled]
Disables or sets the Data Cache BG Scrub. This item allows the data
cache BG Scrub RAM to be corrected when idle. Configuration options:
[Disabled] [40ns] [80ns] [160ns] [320ns] [640ns] [1.28us] [2.56us] [5.12us]
[10.2us] [20.5us] [41.0us] [81.9us] [163.8us] [327.7us] [655.4us] [1.31ms]
[2.62ms] [5.24ms] [10.49ms] [20.97ms] [42.00ms] [84.00ms]
