15 PD-200
3 Quick Starting Guide
3.
Plug AV signal wires into peripheral equipment
Next, plug the other end of AV signal wires into your preferred peripheral equip-
ment. More often than not, this will be a television set. Most TVs have input jacks
for AV signal wires. As with output plugs, please make sure same colored wires
connect to same colored jacks. Please refer to the instruction manual to deter-
mine how to set your TV to receive AV signal input from an external source.
2.
Plug in the AV signal wires
Plug the AV signal wires into the 3 AV output connectors located on the left-side
panel. The red and white output plugs are configured such that the former pro-
vides right speaker audio, while the latter provides right speaker audio. The yel-
low plug provides video output.
