Panasonic SCPMX9EG - Manual (Page 18)

VQT4Z2
1
18
18
ENGL
ISH
Reset the memory when the following situations occur:
• There is no response when buttons are pressed.
• You want to clear and reset the memory contents.
1 Disconnect the AC mains lead.
Wait 3 minutes before you continue with step 2.
2 While you press and hold [Í/I] on the main unit,
connect the AC mains lead again.
“- - - - - - - - - - - -” is shown.
3 Release [Í/I].
All the settings are set back to the factory preset.
It is necessary to set the memory items again.
When other Panasonic equipment responds to the
remote control of this system, change the remote control
code for this system.
To set the code to “Remote 2”
1 Press [CD] to select “CD”.
2 Press and hold [CD] on the main unit and [2] on
the remote control until “Remote 2” is shown.
3 Press and hold [OK] and [2] for a minimum of
4 seconds.
• The factory preset is “Remote 1”.
• To change the mode back to “Remote 1”, repeat the
steps above but replace the button pressed on the
remote control from [2] to [1].
Specifications
RMS output power
Front Ch (both ch driven)
60 W per channel (3 ™), 1 kHz,
10% total harmonic distortion
Total RMS power 120 W
Frequency modulation (FM)
Preset memory 30 stations
Frequency range
87.50 MHz to 108.00 MHz (50 kHz step)
Antenna terminals 75 ™ (unbalanced)
“iPod_Port” connection
DC OUT 5 V 2.1 A (max)
USB standard USB 2.0
Media file format support MP3 (*.mp3), FLAC (*.flac)
USB device file system FAT16, FAT32
ID3 Tag support v2.3
“iPod_Dock” connection
DC OUT 5 V 1.0 A (max)
Headphones jack Stereo, Ø 3.5 mm jack
AUX input (rear) Pin jack
LAN port 10 Base-T/100 Base-TX
Disc played (8 cm or 12 cm)
CD, CD-R/RW (CD-DA, MP3)
Pick up
Wavelength 790 nm (CD)
Laser power CLASS 1
NORSK
Bølgelengde 790 nm (CD)
Laserstyrke Ingen farlig stråling sendes ut
Audio output (Disc)
Number of channels 2 ch (FL, FR)
Speaker unit(s)
Woofer 14 cm cone type x 1
Tweeter 1.9 cm dome type x 1
Super tweeter 1.2 cm piezo type x 1
Impedance 3 ™
Dimensions (W x H x D) 161 mm x 238 mm x 264 mm
Mass Approx. 3.0 kg
Bluetooth ® system specification V 3.0
Wireless equipment classification Class 2
Supported profiles A2DP
Frequency band 2.4 GHz band FH-SS
Driving distance 10 m Line of sight
Prospective communication distance
Measurement environment:
Temperature 25 oC / Height 1 m
Measure in “Mode 1”
MP3
Sampling frequency 32/44.1/48 kHz
Audio word size 16 bits
Channel count 2 ch
Bit-rate 8-320 kbps
FLAC
Sampling frequency
32/44.1/48/88.2/96/176.4/192 kHz
Audio word size 16.24 bits
Channel count 2 ch
WAV (DLNA only)
Sampling frequency
32/44.1/48/88.2/96/176.4/192 kHz
Audio word size 16.24 bits
Channel count 2 ch
Memory reset (initialisation)
Remote control code
Amplifier section
Tuner section
Terminals section
Disc section
Speaker section
Bluetooth ® section
Wi-Fi/AirPlay section
Wi-Fi
WLAN Standard IEEE802.11b/g
Frequency range 2.4 GHz band
Security WEP (64 bit/128 bit),
WPA TM , WPA2 TM
WPS version
Version 2.0 (WEP not support)
Audio Support format (USB, DLNA)
