With this function set to “On”, you can stream music from
the iOS device or Mac / PC (iTunes 10.2.2 or later) to
this system without the need of a network router.
• Previous network settings will be deleted when this
function is set to “On”.
• The following explanations are based on an iPhone.
1 Press [SETUP] repeatedly to select “D.Connect”.
2 Press [2, 1] to select “On” and then press [OK].
3 Press [2, 1] to select “OK? Yes” and then press
[OK].
4 Connect your iPhone to this system’s wireless
network named “PMX9 _ _ _ _ _ _”*
2 .
5
Enter the password that is indicated on this
system’s display.
6 Once the iPhone is connected to this system’s
wireless network, the setup is competed.
7 Continue to step 2 of “Using AirPlay with this
system’s speakers”. (> 9)
• This setting is reset to “Off” when other network settings
are performed. (> 6)
• When “D.Connect” is set to “On”, this system will not be
connected to the Internet. It is not possible to update the
software or check the Wi-Fi signal strength.
• When AirPlay is not being used, disconnect the AirPlay
compatible device from this network.
• When using a computer on this network, make sure that all
the shared files are encrypted.
• This feature is only compatible with the “Open System”
authentication method. It is not compatible with “Shared
Key” authentication method.
*1: “ _ ” stands for a digit.
*2: “ _ ” stands for a digit that is unique to each set.
The first time “D.Connect” is set to “On”, a password for
this system’s network is randomly created and
memorised in this system.
• This password is memorised until it is changed.
1 While “D.Connect” is set to “On”:
Press [SETUP] repeatedly to select “D.Connect”.
2 Press [2, 1] to select “On” and then press [OK].
3 The current password is displayed.
• The 5 digits after “PW” is the password for this
network.
4 Press any button to exit.
1 While “D.Connect” is set to “Off”:
Press [SETUP] repeatedly to select “D.Connect”.
2 Press [2, 1] to select “Change PW” and then press
[OK].
3 Press [2, 1] to select “OK? Yes” and then press
[OK].
4 The new password is displayed.
• The 5 digits after “PW” is the new password for
this network.
5 Press any button to exit.
∫ Note about changing the password
After changing this system’s network password, if you
are not prompted to change the password on the other
devices, the following changes are required.
iOS device (iPod touch/iPhone/iPad)
* 1 :
• Before choosing this system’s network,
1 Select [ ] located beside this system’s wireless
network name.
2 Select “Forget this Network” and then select “Forget”.
3 Select this system’s wireless network and enter the
new password.
Mac/PC:
• If the computer has memorised the old password, be
sure to change the memorised password for this
system’s network to the new one.
• Refer to the devices’s operating instructions for details.
*1:
Steps are based on iOS 6.0.1.
Playing back music files on the
DLNA server
You can share music files stored in the DLNA Certified
media server (PC with Windows 7 installed, smartphone,
etc.) connected to your home network, and enjoy the
contents with this system’s speaker.
Preparation
• Complete the network settings. (> 6)
• Connect your device with DMC (Digital Media
Controller) compatible software installed to the same
home network as this system.
• Add the contents and folder to the libraries of the
Windows Media ® Player or the smartphone, etc.
– Playlist of Windows Media ® Player can play back only
the contents that are stored in the libraries.
1
Turn this system on.
• Check that “ ” is indicated on the display.
• If it doesn’t be indicated, check the network
settings. (> 6)
2 Operate the DMC compatible device and connect
to this system.
• The device name of this system will be displayed
as “Panasonic PMX9 _ _ _ _ _ _”* 1, 2 .
• For details on how to use DMC compatible
devices, refer to the operating instructions of the
devices or the software.
∫ Support format of DLNA client
File formats that are not supported by your DLNA server
cannot be played.
• Depending on the contents and the connected equipment,
playback may not be possible.
*1: “ _ ” stands for a digit that is unique to each set.
*2: The name that is displayed for this system can be
changed from the “Edit STEREO SYSTEM name”
settings. (> 9, “Advanced network settings”)
Directly streaming to this system
(AirPlay)
“PW _ _ _ _ _”* 1 is displayed.
The 5 digits after “PW” is the password for this
network.
PMX9
Display the password
Change the password
Audio codec Example of file extension
MP3 .mp3
WAV .wav
FLAC .flac
