Options/Accessories
990-4053
Installation Guide APC Silcon 480kW 400V UPS
47
6.2
Service Bypass Panel for Parallel Redundant Operation
Service Bypass Panel (SBP)
Mains Supply
System Output
Control
cables
Q003
Q004
Q001b
Q001a
Q002b Q002a
APC Silcon
400V UPS
X020
X021
X020
X021
APC Silcon
400V UPS
Battery
Battery Breaker/
Fuse Box
