VAIO® C1 PictureBook™ Notebook User Guide
46
2
Pull the release button, then push it down toward the slot.
To remove a PC card
1
Double-click
in the task tray.
2
The “Unplug or Eject Hardware” dialog displays.
3
Select the hardware device you wish to remove by clicking it.
4
Click Stop.
5
Confirm the correct device is selected in “Stop a hardware device.”
6
The message, “PC Card can now be safely removed from the system”
appears. Click OK.
7
Gently grasp the card and pull it out.
8
Insert the PC card slot protector into the empty slot.
Release Button
✍
Do not force a card into the slot. It may damage the connector pins.
If you have difficulty inserting a card, check that you are inserting the card with the
correct orientation.
See the manual that came with your PC card for more information on its use.
✍
Follow the procedure below when you remove the PC card while your computer is on.
Failure to follow this procedure may result in a malfunction. If your computer is turned
off, you do not have to follow these instructions.
Release button
