19(E)

Assigning Input Signals to Connectors

Before inputting signals to the BKM-28X, you must
specify the type and format of the signal that will be
input to each connector. To assign input signals to
each connector, use the on-screen INPUT
CONFIGURATION menu of your video monitor.

For information about using the INPUT CONFIGURATION
menu, refer to the manual of your video monitor.

Specifications

General

Power requirements +5 V, ±6 V (supplied from the

monitor)

Power consumption 1 W
Recommended operating temperature

20°C to 30°C (68°F to 86ºF)

Permissible operating temperature

0°C to 40°C (32°F to 104°F)

Operating humidity 0% to 90% (no condensation)
Maximum external dimensions (w/h/d)

25

Ч

256

Ч

245 mm

(

31

/

32

Ч

10

1

/

8

Ч

9

3

/

4

inches)

Mass

550g (1 lb 3 oz)

Input/Output Connectors

BNC

×

6, high impedance, with loop-through output

Signal Characteristics

Analog composite signals

Signal level

Analog composite

1 Vp-p +3 dB/–6 dB

YC

Y: 1 Vp-p ±6 dB
C: 0.286 Vp-p ±6 dB (NTSC

burst signal level)
0.3 Vp-p ±6 dB (PAL burst
signal level)

Return loss

–46 dB min. (6 MHz)

Analog component (Y/R–Y/B–Y, RGB) signals

Signal level

Y/R–Y/B–Y Y: 1 Vp-p ±6 dB

R–Y: 0.7 Vp-p ±6 dB
B–Y: 0.7 Vp-p ±6 dB

R/G/B

1 Vp-p ±6 dB (sync on G)

Frequency characteristics

Y

100 Hz to 6 MHz ±2dB

R–Y/B–Y

100 Hz to 6 MHz ±2dB

R/G/B

100 Hz to 6 MHz ±1dB

Chrominance signal/luminance signal

Delay time error

50 nsec max.

Gain error

5% max.

Aperture compensation (Y/R–Y/B–Y)

Off: 0 dB
On: 2 to 6 dB (5 MHz)

Return loss

–46 dB min. (6 MHz)

Accessories Supplied

Installation Manual (1)

Design and specifications are subject to change
without notice.
