6(E)
Input of serial digital signals
You can input serial digital signals to connectors
1,
3, and 5. You can obtain active loop-through output
of those signals from connectors
2, 4, and 6,
respectively.
You need not attach 75-ohm terminations to
connectors
2, 4, and 6.
Input of analog composite signals
You can input analog composite signals to connectors
7, 9, and !¡. You can obtain loop-through output of
those signals from connectors
8, 0, and !™,
respectively. If you do not wish to use loop-through
output, attach 75-ohm terminators to connectors
8,
0, and !™.
Input of Y/R–Y/B–Y or RGB signals
You can input a Y or G signal to connector
7, an B–Y
or B signal to connector
9, and a R–Y or R signal to
connector
!¡. You can obtain loop-through output of
those signals from connectors
8, 0, and !™,
respectively. If you do not wish to use loop-through
output, attach 75-ohm terminators to connectors
8,
0, and !™.
Assigning Input Signals to Connectors
Before inputting signals to the BKM-21D, you must
specify the type and format of the signal that will be
input to each connector. To assign input signals to
each connector, use the on-screen INPUT
CONFIGURATION menu of your video monitor.
For information about using the INPUT CONFIGURATION
menu, refer to the manual of your video monitor.
Specifications
General
Power requirements +5 V, ±6 V, –15 V (supplied
from the monitor)
Power consumption 11 W
Recommended operating temperature
20°C to 30°C (68°F to 86°F)
Permissible operating temperature
0°C to 40°C (32°F to 104°F)
Operating humidity 0% to 90% (no condensation)
Maximum external dimensions (w/h/d)
25
Ч
256
Ч
245 mm
( 31 /
32
Ч
10 1 /
8
Ч
9 3 /
4
inches)
Mass 770g (1 lb 11oz)
Input/Output Connectors
Digital input BNC
×
3, with active loop-
through output
Analog input BNC
×
3, high impedance, with
loop-through output
Signal Characteristics
Analog composite signals
Signal level 1 Vp-p +3 dB/–6 dB
Luminance signal
Frequency characteristics
Filter off: 100 Hz to 5 MHz ±1 dB
(monochrome signal)
Filter on: –30 dB relative to subcarrier
frequency
Chrominance signals
Demodulation axis
NTSC, PAL: R–Y/B–Y
Chrominance signal band (R–Y, B–Y)
NTSC
COMB filter:
0.9 MHz–3dB
TRAP/BPF filter:
0.7 MHz–3dB
PAL
COMB filter:
1.1 MHz–3dB
TRAP/BPF filter:
0.9 MHz–3dB
Subcarrier reproduction error
±1% max.
Subcarrier synchronization range
±150 Hz min.
Chroma phase adjustment range
NTSC: ±15° min.
PAL: ±10° min.
DG (differential gain) APL 10% to 90%
2% max.
DP (differential phase) APL 10% to 90%
2° max.
Chrominance signal/luminance signal
Delay error 35 nsec max.
Gain error 5% max.
BKM-21D SDI Multi Decoder Adaptor
