Page 57
43
Chapter 4
System Board
This chapter identifies each component on the system board and provides
a detailed description of each connector and jumper on the system board.
O
N
1 2
VGA Monitor
USB1, USB2, Ethernet
Line In
Line Out
LCD Monitor
1394 i.LINK
i.LINK
Sony Panel
USB4
i.LINK
OM04581.VSD
Sony
Memory Stick
Mic
ATX PWR
Memory
PCMCIA
Socket
(unused)
SW1 (Config. switch)
1394 i.LINK
CPU
Secondary IDE
Primary IDE
CPU Fan
to Modem/
USB3
Battery
CD-IN
PWR Fan
Wake On LAN (not used)
