Sony MZ-R70 - Manual (Page 58)

58
On the lid of the battery compartment
The lid of the battery compartment is designed to detach from the main unit
when handled with great force. To reattach the lid to the main unit, follow the
steps below:
1 Place the lid so that the
projections on the lid aligned
with the slots on the main unit.
2 Fit the projection one by one
into the slot as shown in the
illustration.
Note on mechanical noise
The recorder gives off mechanical noise while operating, which is caused by
the power-saving system of the recorder and it is not a problem.
To protect a recorded MD
To record-protect an MD, slide open the tab at the side of the MD. In this
position, the MD cannot be recorded or editted. To record again, slide the tab
back so the tab is visible.
1
2
Projections
Slots
Back of the MD
Record-protect
Tab
