Chapter 3 Jumper Settings and Connectors 33
3.1.4 Connectors
Onboard connectors link the panel PC to external devices such as hard
disk drives or floppy drives. The table below lists the function of each
of the board’s connectors.
Table 3-2: Panel PC connectors
Label Function
J1 AT power connector
J4 Inverter power connector
J6 Internal speaker connector (Reserved)
J8 Front panel control connector (Reserved)
J9 IR connector (Reserved)
CN2 Flat panel display connector
CN3 Flat panel display connector
CN4 PanelLink interface (Reserved)
CN10 FDD connector
CN23 Internal COM4, mouse and touchscreen
power connector
CN16 EIDE hard disk drive connector
CN18 CD-ROM connector
FAN1 CPU fan power connector
FAN2 System fan power connector
SLOT1 PCI/ISA bus expansion connector
