Appendix C Pin Assignments 137
C.9 PanelLink Interface (CN4) (*Reserved)
Table C-9: PanelLink Interface (CN4) (*Reserved)
Pin Signal Pin Signal
1 TXC- 11 TX1+
2 GND 12 NC
3 TXC+ 13 TX2-
4 GND 14 NC
5 TX0- 15 TX2+
6 GND 16 EDGE
7 TX0+ 17 2NDSDA
8 GND 18 Vcc
9 TX1- 19 2NDSCL
10 NC 20 GND
20
1 2
19
18 17
3 4
