Programming
169 10" Modero Widescreen Touch Panels
Text Effects Names
The following is a listing of text effects names (associated with the ^TEF command on page 168).
^UNI
Set Unicode text.
For the ^UNI command (%UN and ^BMF command), the Unicode text is sent as
ASCII-HEX nibbles.
Syntax:
"'^UNI-,,'"Variable: variable text address range = 1 - 4000.button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons
1 = Off state and 2 = On state).unicode text = Unicode HEX value. Example:SEND_COMMAND Panel,"'^UNI-500,1,0041'"Sets the button’s unicode character to ’A’.
Note: To send the variable text ’A’ in unicode to all states of the variable text
button 1, (for which the character code is 0041 Hex), send the following command: SEND_COMMAND TP,"'^UNI-1,0,0041'"Note: Unicode is always represented in a HEX value. TPD4 generates (through the Text
Enter Box dialog) unicode HEX values. Refer to the TPDesign4 Instruction Manual for
more information.Text Effects• Glow -S• Medium Drop Shadow 1• Hard Drop Shadow 1• Glow -M• Medium Drop Shadow 2• Hard Drop Shadow 2• Glow -L• Medium Drop Shadow 3• Hard Drop Shadow 3• Glow -X• Medium Drop Shadow 4• Hard Drop Shadow 4• Outline -S• Medium Drop Shadow 5• Hard Drop Shadow 5• Outline -M• Medium Drop Shadow 6• Hard Drop Shadow 6• Outline -L• Medium Drop Shadow 7• Hard Drop Shadow 7• Outline -X• Medium Drop Shadow 8• Hard Drop Shadow 8• Soft Drop Shadow 1• Medium Drop Shadow 1 with outline • Hard Drop Shadow 1 with outline• Soft Drop Shadow 2• Medium Drop Shadow 2 with outline • Hard Drop Shadow 2 with outline• Soft Drop Shadow 3• Medium Drop Shadow 3 with outline • Hard Drop Shadow 3 with outline• Soft Drop Shadow 4• Medium Drop Shadow 4 with outline • Hard Drop Shadow 4 with outline• Soft Drop Shadow 5• Medium Drop Shadow 5 with outline • Hard Drop Shadow 5 with outline• Soft Drop Shadow 6• Medium Drop Shadow 6 with outline • Hard Drop Shadow 6 with outline• Soft Drop Shadow 7• Medium Drop Shadow 7 with outline • Hard Drop Shadow 7 with outline• Soft Drop Shadow 8• Medium Drop Shadow 8 with outline • Hard Drop Shadow 8 with outline• Soft Drop Shadow 1 with outline• Soft Drop Shadow 2 with outline• Soft Drop Shadow 3 with outline• Soft Drop Shadow 4 with outline• Soft Drop Shadow 5 with outline• Soft Drop Shadow 6 with outline• Soft Drop Shadow 7 with outline• Soft Drop Shadow 8 with outline
Variable:
variable text address range = 1 - 4000.
button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons
1 = Off state and 2 = On state).
unicode text = Unicode HEX value.
Example:
SEND_COMMAND Panel,"'^UNI-500,1,0041'"
Sets the button’s unicode character to ’A’.
Note: To send the variable text ’A’ in unicode to all states of the variable text
button 1, (for which the character code is 0041 Hex), send the following command:
SEND_COMMAND TP,"'^UNI-1,0,0041'"
Note: Unicode is always represented in a HEX value. TPD4 generates (through the Text
Enter Box dialog) unicode HEX values. Refer to the TPDesign4 Instruction Manual for
more information.
Text Effects
• Glow -S • Medium Drop Shadow 1 • Hard Drop Shadow 1
• Glow -M • Medium Drop Shadow 2 • Hard Drop Shadow 2
• Glow -L • Medium Drop Shadow 3 • Hard Drop Shadow 3
• Glow -X • Medium Drop Shadow 4 • Hard Drop Shadow 4
• Outline -S • Medium Drop Shadow 5 • Hard Drop Shadow 5
• Outline -M • Medium Drop Shadow 6 • Hard Drop Shadow 6
• Outline -L • Medium Drop Shadow 7 • Hard Drop Shadow 7
• Outline -X • Medium Drop Shadow 8 • Hard Drop Shadow 8
• Soft Drop Shadow 1 • Medium Drop Shadow 1 with outline • Hard Drop Shadow 1 with outline
• Soft Drop Shadow 2 • Medium Drop Shadow 2 with outline • Hard Drop Shadow 2 with outline
• Soft Drop Shadow 3 • Medium Drop Shadow 3 with outline • Hard Drop Shadow 3 with outline
• Soft Drop Shadow 4 • Medium Drop Shadow 4 with outline • Hard Drop Shadow 4 with outline
• Soft Drop Shadow 5 • Medium Drop Shadow 5 with outline • Hard Drop Shadow 5 with outline
• Soft Drop Shadow 6 • Medium Drop Shadow 6 with outline • Hard Drop Shadow 6 with outline
• Soft Drop Shadow 7 • Medium Drop Shadow 7 with outline • Hard Drop Shadow 7 with outline
• Soft Drop Shadow 8 • Medium Drop Shadow 8 with outline • Hard Drop Shadow 8 with outline
• Soft Drop Shadow 1 with outline
• Soft Drop Shadow 2 with outline
• Soft Drop Shadow 3 with outline
• Soft Drop Shadow 4 with outline
• Soft Drop Shadow 5 with outline
• Soft Drop Shadow 6 with outline
• Soft Drop Shadow 7 with outline
• Soft Drop Shadow 8 with outline
