AMX Modero NXD-1000Vi - Manual (Page 165)

Programming
155 10" Modero Widescreen Touch Panels
"^" Button Commands (Cont.)
^BMC (Cont.) Example 2:
SEND_COMMAND Panel,"'^BMC-150,1,1,315,1,%BR%FT%TX%BM%IC%CF%CT'"
Copies the OFF state border, font, Text, bitmap, icon, fill color and text color of the button
with a variable text address of 315 onto the OFF state border, font, Text, bitmap, icon, fill
color and text color of the button with a variable text address of 150.
^BMF
Set any/all button
parameters by
sending
embedded codes
and data.
Syntax:
"'^BMF-,,'"Variables: variable text address char array = 1 - 4000.button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons
1 = Off state and 2 = On state).level range = 1 - 600 (level value is 1 - 65535).data: ’%B’ = Set the border style name. See theBorder Styles and Programming
Numbers table on page 148.’%B’, = Set the borer style number. See theBorder Styles and
Programming Numbers table on page 148.’%DO<1-5><1-5><1-5><1-5><1-5> = Set the draw order. Listed from bottom to top.
Refer to the ^BDO command on page 153 for more information.’%F’, = Set the font. See theDefault Font Styles and ID
Numbers table on page 147.’%F’ = Set the font. See theDefault Font Styles and ID
Numbers table on page 147.’%MI’ = Set the mask image. Refer to the ^BMI command on page 157 for
more information.’%T’ = Set the text using ASCII characters (empty is clear).’%P’ = Set the picture/bitmap filename (empty is clear).’%I’,’ = Set the icon using values of 01 - 9900 (icon numbers are
assigned in the TPDesign4 Resource Manager tab - Slots section).’%I’ = Set the icon using values of 01 - 9900 (icon numbers are
assigned in the TPDesign4 Resource Manager tab - Slots section).’%J’, = As shown the following telephone keypad alignment chart: ’%JT’ = As shown the above telephone keypad alignment chart,
BUT the 0 (zero) is absolute and followed by ’,,’’%JB’ = As shown the above telephone keypad
alignment chart BUT the 0 (zero) is absolute and followed by ’,,’’%JI’ = As shown the above telephone keypad alignment chart,
BUT the 0 (zero) is absolute and followed by ’,,’"^" Button Commands (Cont.)1478963250Zero can be used for an absolute position
Variables:
variable text address char array = 1 - 4000.
button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons
1 = Off state and 2 = On state).
level range = 1 - 600 (level value is 1 - 65535).
data:
’%B’ = Set the border style name. See theBorder Styles and Programming
Numbers table on page 148.
’%B’, = Set the borer style number. See theBorder Styles and
Programming Numbers table on page 148.
’%DO<1-5><1-5><1-5><1-5><1-5> = Set the draw order. Listed from bottom to top.
Refer to the ^BDO command on page 153 for more information.
’%F’, = Set the font. See theDefault Font Styles and ID
Numbers table on page 147.
’%F’ = Set the font. See theDefault Font Styles and ID
Numbers table on page 147.
’%MI’ = Set the mask image. Refer to the ^BMI command on page 157 for
more information.
’%T’ = Set the text using ASCII characters (empty is clear).
’%P’ = Set the picture/bitmap filename (empty is clear).
’%I’,’ = Set the icon using values of 01 - 9900 (icon numbers are
assigned in the TPDesign4 Resource Manager tab - Slots section).
’%I’ = Set the icon using values of 01 - 9900 (icon numbers are
assigned in the TPDesign4 Resource Manager tab - Slots section).
’%J’, = As shown the following telephone keypad alignment chart:
’%JT’ = As shown the above telephone keypad alignment chart,
BUT the 0 (zero) is absolute and followed by ’,,’
’%JB’ = As shown the above telephone keypad
alignment chart BUT the 0 (zero) is absolute and followed by ’,,’
’%JI’ = As shown the above telephone keypad alignment chart,
BUT the 0 (zero) is absolute and followed by ’,,’
"^" Button Commands (Cont.)
1
4
7 8 9
6
3 2
5
0
Zero can be used for an absolute position
