22

U2751A User’s and Service Guide

2

Operation and Features

Agilent Measurement Manager Operation

Launch the Agilent Measurement Manager software and
select the

Matrix tab. The keyboard shortcut key is Ctrl+M.

Connect the instruments and devices as per your
application. Key in the names of the instruments and devices
in the available text boxes.

Click the cross

-point circles on the software to toggle the

contact on or off. The connection from the row to the
column will be highlighted when the circuit is closed.

Figure 2-2

Panel view of the Agilent Measurement Manager
