Cabling
The following cables are recommended for use with the ICX-250 unit.
Cable
Used for
Description
Voice
FXS Ports
50-pin Amphenol (M) to 50 pin Amphenol
(M) (5’)
Data
Data Ports
EIA530A
DB25M to DB25F (Straight through) (5’)
Data
Data Ports
V.35
DB25M to M34F (Straight through) (5’)
T1
RJ48 Port
RJ48M to RJ48M Shielded (1’)
T1
RJ48 Port
RJ48M to RJ48M Shielded (25’)
AC Power
AC Power Input
AC Power Cable (6’)
