Switches Configuring the ICX-250 25
Issue 1, September 1998 ADCP-62-023
© 1998, ADC Telecommunications, Inc.
!! ATTENTION !! Changing the Supervision type
switches will result in all FXS calls on the affected 12
FXS line group to be reset to the idle state each time a
DIP switch setting is changed. This means any active
calls in that FXS line group will be dropped.
FXS Supervision Table
Legend: (e.g. S1 position 5 = 01001 means Mode = FXS-DN / Type = LS-fd)
LS = Loop Start
LS-fd = Loop Start-Forward Disconnect
GS = Ground Start
GSa = Ground Start Automatic
GSi = Ground Start Immediate
SP = Single Party
UVG = Universal Voice Grade
UVGa = Universal Voice Grade Automatic
(Mode) 1, 2
3, 4, 5 (Type)
000 001 100 101 110
FXS 00 LS LS-fd GS GSa GSi
FXS-DN 01 LS LS-fd GS GSa GSi
FXS-DN-WINK 10 LS LS-fd GS GSa GSi
TR-08 11 SP --- UVG UVGa ---
