１４ -
Channel 3 - rotating gobo rotation :
0-7 No rotation
8-127 forwards gobo rotation from fast to slow
128-135 No rotation
136-255
Backwards gobo rotation from slow to fast
Channel 4 - Shutter, strobe:
0-31 Shutter closed
32-63 Dimmer (close to open)
64-95 Strobe effect slow to fast
96-127 No function (shutter open)
128-159 Pulse-effect in sequences
160-191 No function (shutter open)
192-223 Random strobe effect slow to fast
224-255 No function (shutter open)
Channel 5 - PAN movement :
Channel 6 - TILT movement :
0-7 No Rotation of the mirror barrel
8-127 Forward rotation of the barrel from fast to slow
128-135 No Rotation of the barrel
136-255 Backward rotation of the barrel from slow to fast
Channel 7 - Speed pan/tilt movement:
0 max speed
5-225 max to min speed
226-235 blackout by movement
236-245 blackout by all wheel changing
246-255 no function
