VERTICAL CONTACT TOASTER
6 P/N 1010840 Rev. M 07/14
WARNING
ELECTRICAL SHOCK HAZARD. FAILURE TO
FOLLOW THE INSTRUCTIONS IN THIS MANUAL
COULD RESULT IN SERIOUS INJURY OR DEATH.
• Electrical ground is required on this appliance.
• Do NOT modify the power supply cord plug. If
it does not fit the outlet, have a proper outlet
installed by a qualified electrician.
• Do NOT use an extension cord with this
appliance.
• The toaster should be grounded according to
local electrical codes to prevent the possibil-
ity of electrical shock. It requires a grounded
receptacle with separate electrical lines pro-
tected by fuses or a circuit breaker of the prop-
er rating.
• Check with a qualified electrician if you are
unsure if the appliance is properly grounded.
CAUTION
All electrical connections must be in accordance
with local electrical codes and any other appli-
cable codes.
CAUTION
Bread may burn. Therefore toasters must not be
used near or below curtains or other combustible
walls and materials. Failure to maintain safe oper-
ating distances may cause discoloration or com-
bustion.
Unpacking
1. Remove the unit and all packing materials from
shipping carton.
2. Open the included large box. It should contain the
following:
• Bun Chute (Figure 1) some models only.
• Bun Feeder (Figure 1) some models only.
• Two Release Sheets (Figure 1).
• Owner’s Manual.
• Maintenance Card (some models only).
• Authorized Service Agency Directory.
3. Remove all shipping tape and protective cover-
ings from the unit and parts.
NOTE: If any parts are missing or damaged, con-
tact Antunes Technical Service IMMEDIATELY at 1-
877-392-7854 (toll free in the U.S.) or 630-784-1000.
Equipment Setup
Before placing the toaster into service, pay attention to
the following guidelines:
• Make sure power to the unit is off and the toaster
is at room temperature.
• Do NOT block or cover any openings on the unit.
• Do NOT immerse cord or plug in water.
• Keep cord away from heated surfaces.
• Do NOT allow cord to hang over edge of table or
counter.
• Connect the unit to the proper power supply.
Refer to the specification plate for proper voltage
INSTALLATION
Assembling the Unit
NOTE: The factory has pre-installed a Release
Sheet over the Platen (Figure 1). Verify that it is
properly in place before proceeding.
1. Remove Bun Chute (some models) and Bun
Feeder from the box and install (Figure 1).
IMPORTANT: Make sure heat shield assembly is
activating the Conveyor Safety Interlock Switch
(see Figure 1). The conveyors will not rotate unless
the Heat Shield is in place and Conveyor Safety
Interlock Switch is activated.
WARNING
Failure to use Release Sheets may result in dam-
age to the unit and loss of warranty coverage.
