VERTICAL CONTACT TOASTER
24
P/N 1010840 Rev. M 07/14
1 0011266 Conveyor Belt (Incl. Items Below)
2
0800204 1/2” Pitch Link, Small
2
0800121 3/4” Pitch Link, Large
38
2 2150117 Idler Shaft
2
3 7000322 Conveyor Cover Assy.
(Incl. #29, 52, 61 & 76)
2
4 0010475 Tensioner Assy. (Incl. #40, 76 & 85)
4
5 7000644 Rod, Conveyor Cover
4
6 7000207 Sprocket w/ Setscrew
8
7 7000199 Spacer Kit
1
8 0011444 Control Housing Cover Assy.
1
9 2150118 Drive Shaft
2
10 2100212 Handle
2
11 7000374 Control Board
1
14 7000539 Complete Bearing/Spacer Kit
1
(Incl. #15 & 16)
15 7000296 Ball Bearing (Pack of 2)
1
16 7000167 Bearing & Retainer Kit
6
16A 7000224 Bearing & Retainer Kit
(Incl. six of # 7000167)
1
17 2150181 Drive Sprocket
2
2150109 Drive Sprocket
2
(Mfg. No. 9210213 & 9210401)
2150325 Drive Sprocket (Mfg. No. 9210215)
1
18 2150187 Drive Chain
1
19 0011299 Idler Sprocket & Bearing
1
20 0011300 Bracket, Idler Sprocket Assy.
(Incl. #19, 87, 89, 90, & 91)
1
21 0503589 Bracket, Motor Mounting
1
22 7000240 Drive Motor Kit, Dual Frequency
1
50/60 Hz., 208-240 Volt, 9 RPM
(Incl. #58)
7000364 Drive Motor Kit
1
(Mfg. No. 9210201)
7000269 Gearmotor Kit
1
(Mfg. No. 9210213)
23 2150211 Sprocket w/Setscrew,
1
22 Tooth, for 50 Hz
2150132 Sprocket, 14 Tooth
1
(Mfg. No. 9210208 & 217)
2150173 Sprocket 12 Tooth
1
(Mfg. No. 9210203)
2150112 Sprocket, 28 tooth
1
(Mfg. No. 9210201)
2150120 Sprocket, 25B32 5/16 Bore
1
(Mfg. No. 9210213)
24 7000542 Rocker Switch, On/Off (250 VAC)
1
26 7000370 Relay, Solid State
2
27 4010187 Transformer
1
28 7000416 Conveyor Belt Wrap (Pack of 2)
1
29 7000186 Roller Tensioner Assy. (Pack of 2)
1
(Incl. #52, 61 & 76)
30 0503496 Tensioner Bracket, Right
2
31 0503497 Tensioner Bracket, Left
2
32 1001006 Label, Control
1
33 1001069 Label, Dial Compression
1
34 2100253 Knob, Control
2
35 0011445 End Housing Cover Assy.
1
36 4050214 Thermocouple Platen Assy.
1
37 0021170 Weldment, End Housing
1
38 7000249 Release Sheet (Pack of 3)
-
7000250 Release Sheet (Pack of 10)
-
39 0021169 Control Housing
1
40 7000121 Slide Rail Kit (Incl. two slide rails
2
for tensioners and #85)
41 0021207 Conveyor Cam
2
42 7000176 Thermocouple Retainer Kit
2
43 4030332 High Limit Control
1
45 0503455 Tension Spring, Inner
4
46 0503590 Bracket, Motor
1
47 0700651 Wire Set (not shown)
1
48 0503385 Bun Chute (Mfg. No. 9210200, 201, 1
203, 210 & 217)
48A 0503677 Bun Chute (Mfg. No. 9210202)
1
49 4030348 Auxiliary Heater, 675W/230V
2
50 7000165 Auxiliary Thermocouple Kit
1
51 7000289 Platen (230V)
1
52 2100252 Tape
4
53 0504067 Bracket, Line Filter
1
54 0503150 Heater Clip
2
55 303P127* Hinge Pin, Belt Wrap
2
56 4060355 Terminal Block
1
57 0503533 Bracket, Auxiliary Thermocouple
1
58 4000170 Fan Blade, Motor
1
60 0400315 Strain Relief (International)
1
61 05P2199* Spacer
4
62 0500464 Retainer, Bearing
1
63 040P138* Locknut, 1/2”
1
64 0011528 Heat Shield Assy.
1
0011793 Heat Shield Assy.
1
(Mfg. No. 9210213 Only)
65 325P163* Setscrew, 1/4-28 x 5/16”
8
66 1001192* Label, Caution Hot
1
67 308P183* Screw, Hex, #8-32 x 3/8”
2
68 304P105* Nut, #4-40, “KEPS”
4
69 406P107* Cable Tie
1
70 308P143* Nut, #8-32, “KEPS”
6
71 310P103* Screw, Hex, #10-32 x 1/4”
4
72 310P157* Washer, #10
6
73 308P101* Nut, #8-32
3
74 306P101* Nut, Hex, #6-32
2
75 306P123* Screw, #6-32 x 7/8”
2
Item Part No.
Description
Qty.
Item Part No.
Description
Qty.
REPLACEMENT PARTS (continued)
* Sold only as packages of 10.
