27
VERTICAL CONTACT TOASTER
P/N 1010840 Rev. M 07/14
WIRING DIAGRAM (continued)
HI-LIMIT
CONTROL
POWER SWITCH
240 VAC
LINE FILTER
G L1 L2
S.S. RELAY 2
S.S. RELAY 1
FAN
BASE HEATER
MOTOR
TRANSFORMER
12 VAC
A/C FREQ.
CONVERTER
BOARD
C1
C2
M
F
C1
C2
T. COUPLE
AUXILIARY
T. COUPLE
PLATEN
HI-LIMIT
THERMOSTAT
PLATEN
AUX. HEATER #2
AUX. HEATER #1
INTERLOCK
SWITCHES
(AUXILIARY)
(PLATEN)
TEMP. CONTROL
3 + 4 -
3 + 4 -
3 + 4 -
3 + 4 -
T1 T2 T3
J1A
J1B
J5
J2A
J2B
J4
+ - -
(FOR HEATED
BASE UNITS ONLY)
