LTPH-UM-1109-01, Issue 1 Monitoring System Activity and Performance
H2TU-C-231 List 2 January 9, 2002 37
U
SING THE
R
EPORT
M
ENU
The Report menu ( Figure 25 ) provides screens containing status and performance monitoring data for line and
remote units which can be downloaded to a file for analysis or future reference. Table 13 on page 38 describes the
four types of reports provided by the Report menu.
To select each individual report, do the following:
1 Press to select Report menu.
2 Press the to select a report.
3 Use your terminal emulation software (HyperTerminal or Procomm) to capture the selected report to your
printer or to a file. Press
to generate.
4 End the captured report.
5 Press + to refresh the Report menu screen.
Figure 25. Report Menu - Full Report
O
SPACEBAR
ENTER
CTRL R
Monitor Performance Event Log Config Inventory Report Rlogon Help
Report Type : Full Report
Please select report type by pressing , then start terminal logging
and press to generate the report.
ID: xxxx—-xxxx—-xxxx--xxxx 09/01/2001 12:30:01 H2TU-C System: OK _
