Figure 19. H2TU-C HDSL2 25-Hour Performance History
Figure 20. H2TU-C HDSL2 Current Statistics
Monitor Performance Event Log Config Inventory Report Rlogon Help
H2TU-C HDSL2 25-Hour History (Page 1 of 9)
-----------------------------------------------------------------------------
Time CV ES SES UAS LOSWS
*10:00 - - - - -
*10:15 - - - - -
*10:30 - - - - -
*10:45 - - - - -
11:00 - - - - -
11:15 - - - - -
11:30 - - - - -
11:45 - - - - -
12:00 - - - - -
12:15 14 10 10 12 10
12:30 0 0 0 0 0
12:45 0 0 0 2 0
Press: (N)ext Page, (P)revious Page, C(l)ear History
------------------------------------------------------------------------------
Use to cycle through Interface : H2TU-C HDSL2
choices and to view Statistics : 25-Hour History
ID: xxxx--xxxx--xxxx--xxxx 09/01/2001 12:30:01 H2TU-C System: OK ___
Monitor Performance Event Log Config Inventory Report Rlogon Help
H2TU-C HDSL2 Current Statistics
-----------------------------------------------------------------------------
1 Day 1 Hour 15 Min
Start 00:00 12:00 12:30
CV 0 0 0
ES 0 0 0
SES 0 0 0
UAS 0 0 0
LOSWS 3482 1801 1
Margin(dB) LA (dB)
Hi 16
Cur 15 25
Low 12
Press: C(l)ear Current Statistics
------------------------------------------------------------------------------
Use to cycle through Interface : H2TU-C HDSL2
choices and to view Statistics : Current
ID: xxxx--xxxx--xxxx--xxxx 09/01/2001 12:30:01 H2TU-C System: OK ___
