Part No. 0110-003077
Page 1 of 3
Rev.1 2-28-13 DSL
HEADER INSTALLATION INSTRUCTIONS
PART NUMBER: D6682
APPLICATION
05-10 FORD MUSTANG, 4.6L, 3V
PerTronix ©
thanks you for choosing
DOUG’S HEADERS, the best fitting, highest quality header on the market. In order
to realize the full potential of our good fit, please read and understand these instructions completely prior to starting work.
CHECK TO MAKE SURE YOU RECEIVED THE PROPER PARTS FOR YOUR APPLICATION. THE HEADER NUMBER WILL
BE STAMPED ON THE ENGINE FLANGE. IF YOU ARE UNSURE YOU HAVE RECEIVED THE PROPER PARTS CALL
BEFORE YOU START WORK.
BE SURE TO WORK SAFE! WHENEVER YOU WORK UNDER THE VEHICLE BE SURE THAT IT IS LOCATED ON LEVEL,
SOLID GROUND AND IS SUPPORTED BY ADEQUATE SAFETY STANDS!
REMEMBER: HOT ASPHALT WILL NOT SUPPORT MOST JACK STANDS!
Many factors affect the installation of headers, some of which are broken or aftermarket motor mounts, accidents that impact the
configuration of the frame, and/or the installation of different engines or aftermarket cylinder heads. Most installations require
some welding. If you are uncomfortable with welding operations, we recommend that you contact a professional exhaust
system specialist to install your new headers.
Attention Customers breaking in new engines: Due to the extreme heat generated during the break-in process, the
appearance of the ceramic coating may be altered in certain areas. The protection characteristics and thermal barrier properties
of the coating is never compromised. It is recommended that a cast iron manifold or old set of headers be used for this process.
Notice: The coating of these headers can be marred or scratched during installation. If the header needs to be returned and is
damaged, you will be charged for recoat.
Note 1: Remove the O
2
sensors from the factory H-pipe and label each one for
correct positioning later
Note 2: The aluminized X-pipe kit (D925) is a direct bolt on component, designed to
fit with the D6682 header. The D6682 header is also designed to allow for re-
use of the factory H-pipe.
DISASSEMBLY / ASSEMBLY
LEFT SIDE:
1. Disconnect the negative battery cable from the battery.
2. If a car lift is not available, raise the vehicle 2 feet or higher and support it with
adequate safety stands. Make sure the vehicle is on a flat solid surface and is stable.
3. Apply penetrating oil to all nuts and bolts to be removed.
4. Remove the factory H-pipe.
5. Remove the left side stock manifold and all studs.
Very Important: Use a 5mm hex socket for the studs.
